| Rating | 1500 HP |
| Hook Load | 700,000 lbs@ 12 lines |
| Drilling Depth | 16,500 ft |
| Height | 147.5 ft |
| Static Hook Load | 700,000 lbs |
| Floor Height | 29.5 ft |
| Clear Height | 25 ft |
| Rotary Capacity | 700,000 lbs |
| Setback Capacity | 400,000 lbs |
| Rated Power | 1500 HP |
| Capacity | 700,000 lbs@ 12 lines |
| Drill Line Size | 1 3/8” |
| Block Model | TC315 |
| Block Capacity | 700,000 lbs |
| Rotary Table Model | ZP375 |
| Rotary Table Clearance | 37-1/2 in |
| Top Drive Model | Varco-TDS11SA |
| Top Drive Capacity | 500 ton |
| Torque-Continuous | 37,500 ft lb @ 125 rpm |
| Engines | 3set,CAT 3512B,1310 Kw@1500rpm |
| Generators | 3set,SR4B, 600V,50Hz,1900kVA |
| VFD | VFD RIG |
| Annular | 13-5/8”, 5,000 psi |
| Double Ram | 13-5/8”, 10,000 psi |
| Single Ram | 13-5/8”, 10,000 psi |
| Annular | 21-1/4”, 2,000 psi |
| BOP Control Unit | FKQ1280-7 |
| Mud Pump | 3set, BOMCO, F-1600 , Triplex |
| Shale Shaker | 3set, NOV Brandt King Cobra VENOM |
| Mud cleaner |
combo type shale shaker with desander and desilter desander 100mmx16 Cones desilter 250mmx3 Cones |
| Total Tank Volume | 2500 bbl |
| Active Tank Volume | 1500 bbl |
| Reserve Tank Volume | 1000 bbl |
