| Rating | 2000 HP |
| Hook Load | 1,000,000 lbs@ 12 lines |
| Drilling Depth | 23,000 ft 7000m |
| Height | 152 ft 46.5m |
| Static Hook Load | 1,000,000 lbs |
| Floor Height | 34.5 ft 10.5m |
| Clear Height | 29.5 ft 9m |
| Rotary Capacity | 1,000,000 lbs |
| Setback Capacity | 500,000 lbs |
| Rated Power | 2000 HP |
| Capacity | 1,000,000 lbs@ 12 lines |
| Drill Line Size | 1 1/2” |
| Block Model | TC450 |
| Block Capacity | 1,000,000 lbs |
| Rotary Table Model | ZP375 |
| Rotary Table Clearance | 37-1/2 in |
| Top Drive Model | NOV TDS-11SA |
| Top Drive Capacity | 500 ton |
| Torque-Continuous | 37,500 ft lb @ 125 rpm |
| Engines | 4set, CAT 3512B, 1310 Kw@1500rpm |
| Generators | 4set,SR4B, 600V,50Hz,1900kVA |
| SCR | SCR RIG |
| Annular | 13-5/8”, 5,000 psi |
| Double Ram | 13-5/8”, 5,000 psi |
| Single Ram | 13-5/8”, 5,000 psi |
| Annular | 21-1/4 in, 2,000 psi |
| BOP Control Unit | FKQ1280-7 |
| Mud Pump | 3 set, BOMCO, F-1600 , Triplex |
| Shale Shaker | 3 set, NOV Brandt King Cobra VENOM |
| Mud cleaner |
Combo type shale shaker with desander and desilter Desander 100mmx16 Cones Desilter 250mmx3 Cones |
| Total Tank Volume | 3000 bbl |
| Active Tank Volume | 2000 bbl |
| Reserve Tank Volume | 1000 bbl |
